Magnetron53 MG5256 X-Band Magnetron ABRIDGED DATA rugged, lightweight, fixed frequency pulse magnetron, Operating frequency 9375 ± 30 MHz Typical peak output power 12.5 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 0.7 kg approx Heater current at 6.3V 0.5 A Mounting p.. 2012. 6. 26. MG5257 X-Band Magnetron ABRIDGED DATA rugged, lightweight, fixed frequency pulse magnetron, electically and mechanically interchangeable with 2J42 and M503A. Operating frequency 9410 ± 30 MHz Typical peak output power 12.5 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3.. 2012. 6. 26. MG5388C X-Band Magnetron ABRIDGED DATA Compact, rugged, lightweight, fixed frequency pulse magnetron Operating frequency 9410 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 500 g approx Heater current at 6.3V 0.55 A Mounting position any Cathode pre-heating time (minimu.. 2012. 6. 25. MG5388 X-Band Magnetron ABRIDGED DATA Compact, rugged, lightweight, fixed frequency pulse magnetron Operating frequency 9410 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 500 g approx Heater current at 6.3V 0.5 A Mounting position any Cathode pre-heating time (minimum.. 2012. 6. 25. MG5243 X-Band Magnetron ABRIDGED DATA Compact, rugged, lightweight, fixed frequency pulse magnetron Operating frequency 9445 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 0.7 kg approx Heater current at 6.3V 0.5 A Mou.. 2012. 6. 25. MG5251 X-Band Magnetron ABRIDGED DATA Lightweight, fixed frequency pulse magnetron. It is electrically and mechanically interchangeable with M5196F. Operating frequency 9410 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweig.. 2012. 6. 25. M1437A X-Band Magnetron GENERAL DATA Electrical Heater Voltage(Preheat) Min Typical Max Unit 5.7 6.3 6.9 V Heater Voltage(Operation) - 3.7(note 1) - V Preheat time 120 - - S Peak anode voltage 7.5 8.0 8.5 kV Rate of rise of voltage pulse - 70 100 kV/μs Peak anode current 6.0 8.0 10.0 A Mean anode current 6.0 8.0 10.0 mA Peak anode input power - - 75 kW Mean anode input power - - 85 W Pulse duration (Ditected R.F) 0.05 .. 2012. 6. 19. MG5353 X-Band Magnetron TYPICAL OPERATION Heater voltage Min Typical Max - 6.3 - V Heater current - 0.6 - A Pulse duration - 0.9 - ms Pulse repetition rate - 1000 - pps Peak anode voltage - 1.9 - kV Peak anode current - 2.0 - A Peak output power 1.2 1.5 - kW Mean output power 0.6 0.75 - W RF bandwidth - 2.4 - MHz Sidelobe amplitude - -9 - dB Frequency 9380 - 9440 MHz Missing pulses - - 0.01 % MECHANICAL Overall dimensi.. 2012. 6. 19. MG5223F S-Band Magnetron ABRIDGED DATA Fixed frequency pulse magnetron. Operating frequency 3050 ± 10 MHz Typical peak output power 30 kW Magnet integral Coupler mates with NATO S.N. 5985-99-083-0058 Electrical Cathode indirectly heated Heater voltage (see note 1) 6.3 V Heater current at 6.3V 1.25 A Cathode pre-heating time (minimum) 180 s Heater starting current, peak value, not to be exceeded 6.0 A max Mechanical Over.. 2012. 6. 15. 이전 1 2 3 4 5 6 다음
