MG5223F S-Band Magnetron ABRIDGED DATA Fixed frequency pulse magnetron. Operating frequency 3050 ± 10 MHz Typical peak output power 30 kW Magnet integral Coupler mates with NATO S.N. 5985-99-083-0058 Electrical Cathode indirectly heated Heater voltage (see note 1) 6.3 V Heater current at 6.3V 1.25 A Cathode pre-heating time (minimum) 180 s Heater starting current, peak value, not to be exceeded 6.0 A max Mechanical Over.. 2012. 6. 15.
Accessories and magnets for linear accelerator magnetrons E2V Part No. Used on Description MG6062 MG5125, MG5125P, MG5125X, MG5193, MG6060 Water cooled electromagnet MG6053 MG5349, MG6090 Water cooled electromagnet MG6030 MG5028, MG6028 Water cooled electromagnet and transition to UG-53/U M4152S MG5125, MG5125P, MG5125X, MG5193, MG6060 Transition section to WG10/WR284 rectangular flange CPR284F MA761 M5028 Radiation absorber MG6016 MG6028 Radiation abs.. 2011. 11. 8.
RF Receivers Parts List(RF 리시버) E2V Part No. Frequency (MHz) MDS (dBm typical) Noise figure (dB max) Power supplies B3IM16161 9.3 - 9.5 -100 4.7 +15, +5, -15 4 bandwidths, perfomance monitoring, AFC B3IM16171 9.1 - 9.3 -100 4.7 +15, +5, -5.2 Frequency variant of B3IM1616 2011. 8. 16.
Noise generators Parts List(노이즈 제너레이터) E2V Part No. Frequency (MHz) ENR (dB max) Incident power pulsed, 1µs (kW max) Power supplies B3NG1639 8.8 - 9 15 60 +21 V, 0 - 25 mA Waveguide (WG16) cal. frequency 8900 GHz B3NG1641 9.3 - 9.5 15 60 +21 V, 0 - 25 mA Waveguide (WG16), cal. frequency 9.375 GHz B3NG1642 9.3 - 9.5 15 60 +21 V, 0 - 25 mA Waveguide (WG16), cal. frequency 9.410 GHz B3NG1004 3000 - 3100 15 60 +24 V, 0 - 30 mA Waveguide .. 2011. 8. 16.
Front ends Parts List(프론트엔드) E2V Part No. Frequency (MHz) Gain (dB min) Noise figure (dB max) Power supplies B7RX1001 3.02 - 3.08 6 3 +12 V, Vr 4 - 24 V IF output BNC female, filtered power supplies B7RX1002 3.02 - 3.08 6 3 +12 V, Vt 4-24 V Feedthrough pin connectors B7RX1008 3.02 - 3.08 6 3 +12 V, Vt 4-24 V IF output BNC female, RF input filter B3RX1612 9.3 - 9.5 2.5 3.5 +5 V, Vt 4-24 V PCB edge connector B3RX1613 9.36 - 9.. 2011. 8. 16.
Circulators Parts List(서큘레이터) e2v technologies manufacture Ferrite Devices operation from 350 MHz to 120 GHz, for a wide variety of applications from low cost marine radar to state-of-the-art military devices. Standard units are available in regular waveguide sizes and some special sizes. e2v technologies offer circulators and isolators as stand-alone units and also as part of an integrated microwave package. They all come w.. 2011. 8. 16.
Limiters Parts List(리미터) E2V Part No.Frequency (MHz)Peak Power(kW)STCAttenuation(dB)Length(mm)B3LT16129300 - 950010　35B3LT10083020 - 3080303055B3LT1014B3020 - 308030　112B3LT10143020 - 308030　74BS1693030 - 307025　32.9B6LT10693030 - 307025　32.9B3LT161048800 - 900030　44B3LT161248800 - 9000303044B3LT16109300 - 950010　35B3LT16689360 - 9460252535B3LT161149300 - 950050　60B3LT10183020 - 3080303055B3LT10233020 - 3080303055B3LT16.. 2011. 8. 16.
E2V MG5193 Tunable S-Band Magnetron GENERAL DATA Electrical Mechanical Frequency range (cooling water 40˚C) 2993 to 3002 MHz Output to no.10(WR284) waveguide (72.14 x 34.04 mm internal) Peak output power 2.6 MW Overall dimensions see Outline Cathode indirectly heated Net weight 8kg approx Heater voltage (see note 2) 8.5 V dc Mounting position (see note 4) any Heater current 9.0 A Tuner revolutions to cover frequency range (see not.. 2011. 8. 12.
About e2v e2v technologies are the manufacturers of the world-renowned EEV brand of marine radar magnetrons and components. EEV products are meeting all requirements for the multitude of system types used today. Today e2v technologies are recognised as a specialist supplier of RF, microwave and sensing component and sub-systems with a strong, and in a number of cases leading, positions in global, niche ma.. 2010. 12. 21.
