Marine Radar Parts68 MG5255 X-Band Magnetron ABRIDGED DATA rugged, lightweight, fixed frequency pulse magnetron, Operating frequency 9410 ± 30 MHz Typical peak output power 6.0 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 0.7 kg approx Heater current at 6.3V 0.5 A Mounting po.. 2012. 6. 26. MG5256 X-Band Magnetron ABRIDGED DATA rugged, lightweight, fixed frequency pulse magnetron, Operating frequency 9375 ± 30 MHz Typical peak output power 12.5 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 0.7 kg approx Heater current at 6.3V 0.5 A Mounting p.. 2012. 6. 26. MG5257 X-Band Magnetron ABRIDGED DATA rugged, lightweight, fixed frequency pulse magnetron, electically and mechanically interchangeable with 2J42 and M503A. Operating frequency 9410 ± 30 MHz Typical peak output power 12.5 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3.. 2012. 6. 26. MG5388C X-Band Magnetron ABRIDGED DATA Compact, rugged, lightweight, fixed frequency pulse magnetron Operating frequency 9410 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 500 g approx Heater current at 6.3V 0.55 A Mounting position any Cathode pre-heating time (minimu.. 2012. 6. 25. MG5388 X-Band Magnetron ABRIDGED DATA Compact, rugged, lightweight, fixed frequency pulse magnetron Operating frequency 9410 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 500 g approx Heater current at 6.3V 0.5 A Mounting position any Cathode pre-heating time (minimum.. 2012. 6. 25. MG5243 X-Band Magnetron ABRIDGED DATA Compact, rugged, lightweight, fixed frequency pulse magnetron Operating frequency 9445 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweight 0.7 kg approx Heater current at 6.3V 0.5 A Mou.. 2012. 6. 25. MG5251 X-Band Magnetron ABRIDGED DATA Lightweight, fixed frequency pulse magnetron. It is electrically and mechanically interchangeable with M5196F. Operating frequency 9410 ± 30 MHz Typical peak output power 4.0 kW Magnet integral Out put No.16 waveguide(0.900x0.400 inch internal) Coupler IEC UBR100 Electrical Mechanical Cathode indirectly heated Overall dimensions see outline Heater voltage (see note 1) 6.3 V Netweig.. 2012. 6. 25. 마그네트론의 원리 및 응용분야와 전망 마그네트론 발진기 (Magnetron oscillator)는 전기장과 자기장이 서로 수직으로 인가되는 교차장 (Crossed field)이 존재하는 고진공속에서 발생된 전자빔 (Electron beam)의 전기에너지를 고출력 전자기파 (Electromagnetic wave) 에너지로 변환하여 방사하는 고효율, 고출력의 전자기파 발생장치이다. 마그네트론 발진기는 1930년대 최초로 고안되었고, 제2차 세계대전을 기점으로 레이더 (Radar) 응용을 위해 영국과 미국을 중심으로 본격적으로 연구개발 되었으며, 그 후 전자기파의 정보 전달과 에너지 전달의 특성을 이용한 산업, 국방, 의료, 환경, 과학, 에너지 분야 등에 응용되어 다양하게 사용되고 있다. 1. 마그네트론 발진기 동작원리 마그네트론 발진기는 전자.. 2012. 6. 21. E2V 레이더 퍼포먼스 모니터 E2V Part No. Band B3RX1013 S-Band B3RX1652 X-Band 2012. 6. 20. 이전 1 ··· 3 4 5 6 7 8 다음
