KUM481-1 안테나는 2섹션으로 나눠져 있으며 레저선이나 무역선 모두 사용 가능한
무지향성 안테나입니다.

KUM481-1 안테나는 유리섬유 재질로 제작하여 튼튼하고 가벼우며 폴리우레탄 락카로
마무리 되어 전기적 부식과 험한 바다 환경에 잘 견딜 수 있도록 만들어졌습니다.



CE(유럽인증)을 획득한 국제적으로 인증된 제품이며 깔끔한 마무리로 한층 고급스러움을 더했습니다.


posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM803-1 안테나는 3섹션으로 나눠져 있으며 어선이나 무역선 모두 사용 가능한 무지향성 안테나입니다.

KUM803-1 안테나는 유리섬유 재질로 제작하여 튼튼하고 가벼우며 폴리우레탄으로 마무리 되어 전기적 부식과 험한 바다 환경에 잘 견딜 수 있도록 만들어졌습니다.





CE(유럽인증)을 획득한 국제적으로 인증된 제품이며 깔끔한 마무리로 한층 고급스러움을 더했습니다.


posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM603-1 안테나는 2섹션으로 나눠져 있으며 레저선이나 무역선 모두 사용 가능한 무지향성 안테나입니다.

KUM603-1 안테나는 유리섬유 재질로 제작하여 튼튼하고 가벼우며 폴리우레탄 락카로 마무리 되어 전기적 부식과 험한 바다 환경에 잘 견딜 수 있도록 만들어졌습니다.

CE(유럽인증)을 획득한 국제적으로 인증된 제품이며 깔끔한 마무리로 한층 고급스러움을 더했습니다.


posted by (주)얼라이드이파트(AEP) 얼라이드이파트



OUR new improved KUM-antennas – approved for –55 degrees Celsius - are now available. The enhanced KUM antennas are offered at the same price as OUR previous KUM antennas.

In our world quality is the key to a successful business. Therefore, we have our main focus centered on the quality of our products, and we continuously strive towards improvements whenever it is possible. This has already led to the launch of our new and improved CX4 family and now we are very proud to introduce our new and improved HF/SSB antenna family as well.

The enhanced KUM-antennas are released as follows:



KUM-SERIES RELEASE DATES
KUM600 Available today
KUM480 Ultimo February
KUM803 Medio March
All others KUM models During Q2 and Q3 2015



Before the enhancements OUR KUM-antennas were among the strongest on the market. With the new enhanced KUM antennas we probably have the strongest HF/SSB series. The improvements are:

    Stronger glass fiber.
    The glass fiber radomes on the antennas are much stronger than our old models. Today our cylindrical glass fiber radomes have a guaranteed strength of minimum 900MPa.

    More than 4 times stronger build-up inside the antennas.
    Today we are using modern assembly techniques such as crimping instead of soldering the radiating elements of the antennas. As a result of this, the antennas are more than 4 times stronger on the inside, making it extremely vibration resistant over the full temperature range.

    Stronger paint on the glass fiber.
    The painting of the glass fiber is done in one of the world’s most advanced painting factories, where dosage, drying process etc. are under the best controlled conditions. This ensures an outstanding adhesive effect of paint onto the glass fiber.

Stronger Chrome Brass assemblies.
Our Chrome Brass parts are stronger than our old models, and they have a more aerodynamic design giving less win load surface to the antennas.

Other enhancements:

Stronger chrome layer.
The chrome processes are carried out in Germany by one of the best chrome companies in the world. Our need for very high protection towards corrosion is ensured by having our own special chrome bath process at our supplier – developed for and only used by AC Antennas.

Set screws for all assemblies.
The new models offer set screw sets for all chrome brass assemblies (except for KUM603 and KUM703) securing the fixation of the antenna parts.

Improved assemblies ensure easy and correct installation.
The new models are developed with a socket width assembly to secure installation with the correct torque. All models are of course still supplied with a detailed Installation Guide.

Fewer spare parts.
All the KUM-antennas (KUM4XX – KUM9XX) are manufactured using fewer different parts (top-, middle- and bottom sections), which results in fewer spare parts.

New enhanced connection box will be available beginning of Q2 2015.
A new and improved connection box will be introduced during Q2 2015 for all our KUM antennas. The box will be stronger and have a much easier connection feature.



'Marine Antenna > HF/SSB Antenna' 카테고리의 다른 글

HF/SSB 안테나 KUM803-1 (1.4-30 MHz)  (0) 2017.07.13
HF/SSB 안테나 KUM603-1 (1.4-30 MHz)  (0) 2017.05.25
OUR new enhanced HF/SSB antennas now available  (0) 2015.04.28
KUM600-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM600-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM600 (1.4-30.0MHz)  (0) 2013.12.13
posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM600-2 is a 2 section omnidirectional side-fed HF transceiver antenna for automatic antenna tuned systems
for both leisure and commercial vessels.
The KUM600-2 is manufactured in premium quality materials in order to prevent galvanic corrosion.
Radiating element is made of copper.

KUM600-2 is sold worldwide during more than three decades. The antenna is subject for improvement at all times.
The antenna has the same rugged design as all other AC Marine antennas thus it withstands harsh environmental conditions.



GENERAL DATA

Electrical specifications

 Frequency range (MHz)  1.4-30.0

 Maximum Power (watts)

 750 PEP
 Insulation Resistance  > 10 E9
 Pattern  Vertical
 Polarization  Vertical
 Static Capacitance (pF)  70
 Maximum HF Voltage (kV)  9

Mechanical specifications

 Height (meter/ft.)  6.0 / 19.7
 Weight (kg/lbs.)  2.5 / 5.6
 Wind load @ 160 km/h (N)  150
 Finish  Polyurethane lacquer
 Colour  White
 Temperature range (°C / °F)  -40 to +60 / -40 to 140

K493F Conection Box

Mounting:
No mounting included.
K493F connection transformer box is included, for receiver function at low
frequencies or long feeder cable..
Can be used with standard AC Marine mounting, two mounts per antenna:
N070F, N075F, N080F, N085F & N090F.





'Marine Antenna > HF/SSB Antenna' 카테고리의 다른 글

HF/SSB 안테나 KUM603-1 (1.4-30 MHz)  (0) 2017.05.25
OUR new enhanced HF/SSB antennas now available  (0) 2015.04.28
KUM600-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM600-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM600 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-2 (1.4-30.0MHz)  (0) 2013.12.13
posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM600-1 is a 2 section omnidirectional side-fed HF transceiver antenna for automatic antenna tuned systems
for both leisure and commercial vessels.
The KUM600-1 is manufactured in premium quality materials in order to prevent galvanic corrosion.
Radiating element is made of copper.

KUM600-1 is sold worldwide during more than three decades. The antenna is subject for improvement at all times.
The antenna has the same rugged design as all other AC Marine antennas thus it withstands harsh environmental conditions.



GENERAL DATA

Electrical specifications

 Frequency range (MHz)  1.4-30.0

 Maximum Power (watts)

 750 PEP
 Insulation Resistance  > 10 E9
 Pattern  Vertical
 Polarization  Vertical
 Static Capacitance (pF)  70
 Maximum HF Voltage (kV)  9

Mechanical specifications

 Height (meter/ft.)  6.0 / 19.7
 Weight (kg/lbs.)  2.5 / 5.6
 Wind load @ 160 km/h (N)  150
 Finish  Polyurethane lacquer
 Colour  White
 Temperature range (°C / °F)  -40 to +60 / -40 to 140

K483F Conection Box

Mounting:
No mounting included.
K483F connection box for connection with coaxial cable included.
Can be used with standard AC Marine mounting, two mounts per antenna:
N070F, N075F, N080F, N085F & N090F.

'Marine Antenna > HF/SSB Antenna' 카테고리의 다른 글

OUR new enhanced HF/SSB antennas now available  (0) 2015.04.28
KUM600-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM600-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM600 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-1 (1.4-30.0MHz)  (0) 2013.12.13
posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM600 is a 2 section omnidirectional side-fed HF transceiver antenna for automatic antenna tuned systems
for both leisure and commercial vessels.
The KUM600 is manufactured in premium quality materials in order to prevent galvanic corrosion.
Radiating element is made of copper.

KUM600 is sold worldwide during more than three decades. The antenna is subject for improvement at all times.
The antenna has the same rugged design as all other AC Marine antennas thus it withstands harsh environmental conditions.



GENERAL DATA

Electrical specifications

 Frequency range (MHz)  1.4-30.0

 Maximum Power (watts)

 750 PEP
 Insulation Resistance  > 10 E9
 Pattern  Vertical
 Polarization  Vertical
 Static Capacitance (pF)  70
 Maximum HF Voltage (kV)  9

Mechanical specifications

 Height (meter/ft.)  6.0 / 19.7
 Weight (kg/lbs.)  2.5 / 5.6
 Wind load @ 160 km/h (N)  150
 Finish  Polyurethane lacquer
 Colour  White
 Temperature range (°C / °F)  -40 to +60 / -40 to 140



Mounting:
No mounting included.
Can be used with standard AC Marine mounting, two mounts per antenna:
N070F, N075F, N080F, N085F & N090F.

'Marine Antenna > HF/SSB Antenna' 카테고리의 다른 글

KUM600-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM600-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM600 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM481 (1.4-30.0MHz)  (0) 2013.12.13
posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM481-2 is a 2 section omnidirectional side-fed HF transceiver antenna for automatic antenna tuned systems
for both leisure and commercial vessels.
The KUM481-2 is manufactured in premium quality materials in order to prevent galvanic corrosion.
Radiating element is made of copper.

KUM481-2 is sold worldwide during more than three decades. The antenna is subject for improvement at all times.
The antenna has the same rugged design as all other AC Marine antennas thus it withstands harsh environmental conditions.



GENERAL DATA

Electrical specifications

 Frequency range (MHz)  1.4-30.0

 Maximum Power (watts)

 500 PEP
 Insulation Resistance  > 10 E9
 Pattern  Vertical
 Polarization  Vertical
 Static Capacitance (pF)  55
 Maximum HF Voltage (kV)  9

Mechanical specifications

 Height (meter/ft.)  4.8 / 15.7
 Weight (kg/lbs.)  2.2 / 4.9
 Wind load @ 160 km/h (N)  99
 Finish  Polyurethane lacquer
 Colour  White
 Temperature range (°C / °F)  -40 to +60 / -40 to 140

K493F connection box

Mounting:
No mounting included.
K493F connection transformer box is included, for
receiver function at low frequencies or long feeder cable.
N200F upper support is required. To be ordered separately.
Can be used with all 1” standard AC Marine mounting.



'Marine Antenna > HF/SSB Antenna' 카테고리의 다른 글

KUM600-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM600 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM481 (1.4-30.0MHz)  (0) 2013.12.13
KUM480-2 (1.4-30.0MHz)  (0) 2013.12.12
posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM481-1 is a 2 section omnidirectional side-fed HF transceiver antenna for automatic antenna tuned systems
for both leisure and commercial vessels.
The KUM481-1 is manufactured in premium quality materials in order to prevent galvanic corrosion.
Radiating element is made of copper.

KUM481-1 is sold worldwide during more than three decades. The antenna is subject for improvement at all times.
The antenna has the same rugged design as all other AC Marine antennas thus it withstands harsh environmental conditions.



GENERAL DATA

Electrical specifications

 Frequency range (MHz)  1.4-30.0

 Maximum Power (watts)

 500 PEP
 Insulation Resistance  > 10 E9
 Pattern  Vertical
 Polarization  Vertical
 Static Capacitance (pF)  55
 Maximum HF Voltage (kV)  9

Mechanical specifications

 Height (meter/ft.)  4.8 / 15.7
 Weight (kg/lbs.)  2.2 / 4.9
 Wind load @ 160 km/h (N)  99
 Finish  Polyurethane lacquer
 Colour  White
 Temperature range (°C / °F)  -40 to +60 / -40 to 140

K483F connection box

Mounting:
No mounting included.
K483F connection box for connection with coaxial cable included.
N200F upper support is required. To be ordered separately.
Can be used with all 1” standard AC Marine mounting.

'Marine Antenna > HF/SSB Antenna' 카테고리의 다른 글

KUM600 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-2 (1.4-30.0MHz)  (0) 2013.12.13
KUM481-1 (1.4-30.0MHz)  (0) 2013.12.13
KUM481 (1.4-30.0MHz)  (0) 2013.12.13
KUM480-2 (1.4-30.0MHz)  (0) 2013.12.12
KUM480-1 (1.4-30.0MHz)  (0) 2013.12.12
posted by (주)얼라이드이파트(AEP) 얼라이드이파트

KUM481 is a 2 section omnidirectional side-fed HF transceiver antenna for automatic antenna tuned systems
for both leisure and commercial vessels.
The KUM481 is manufactured in premium quality materials in order to prevent galvanic corrosion.
Radiating element is made of copper.

KUM481 is sold worldwide during more than three decades. The antenna is subject for improvement at all times.
The antenna has the same rugged design as all other AC Marine antennas thus it withstands harsh environmental conditions.



GENERAL DATA

Electrical specifications

 Frequency range (MHz)  1.4-30.0

 Maximum Power (watts)

 500 PEP
 Insulation Resistance  > 10 E9
 Pattern  Vertical
 Polarization  Vertical
 Static Capacitance (pF)  55
 Maximum HF Voltage (kV)  9

Mechanical specifications

 Height (meter/ft.)  4.8 / 15.7
 Weight (kg/lbs.)  2.0 / 4.9
 Wind load @ 160 km/h (N)  99
 Finish  Polyurethane lacquer
 Colour  White
 Temperature range (°C / °F)  -40 to +60 / -40 to 140



Mounting:
No mounting included.
N200F upper support is required. To be ordered separately.
Can be used with all 1” standard AC Marine mounting.
